M.A.S Horizontal stop device HA 4
Product number:
MAS-33013
EAN:
delivery time: 2-4 days
CHF 117.71*
Content:
1 Stück
Downloads
Product information "M.A.S Horizontal stop device HA 4 "
The HA 4 is a horizontal movable guide for anchorage devices of class B + C of EN 795. The HA 4 connects up to -5 individual anchorage points with each other, whereby the field width is max. 10 m. The horizontal inclination must not exceed 15°. The inclination in the horizontal must not exceed 15°. The minimum distance to the fall edge is 2.5 m.
Sizes:
- Art. no.33016: length 16 m, 2 pcs.
- Item no.33019: length 19 m, 2 pieces
- Item no.33020: length 20 m, 2 pieces
- Item no.33022: length 22 m, 2 pieces
- Item no.33023: length 23 m, 2 pieces
- Item no. 33025: length 25 m, 2 pieces
- Item no.33030: length 30 m, 3 pieces
Properties:
- Standard: EN 795:2012-07 (D), type B + C
- twisted rope ø16 mm x 13 m
- 1 loose hook
